Model |
Diameter (mm) |
Thickness (mm) |
Bore (mm) |
Dowel Pins |
|---|---|---|---|---|
|
G1D78/60L20d30 |
78 |
20 |
30 |
Ø60 (10mm) |
|
G1D84/70L20d46 |
84 |
20 |
46 |
Ø70 (10 mm) |
|
G1D88/63L20d40 |
88 |
20 |
40 |
Ø63 (10 mm) |
|
G1D88/73L20d40 |
88 |
20 |
40 |
Ø73 (10 mm) |
|
G1D88/73L20d54 |
88 |
20 |
54 |
Ø73 (10 mm) |
|
G1D98/60L20d50 |
98 |
20 |
50 |
Ø60 (7 mm) |
|
G1D98/73L20d46 |
98 |
20 |
46 |
Ø73 (10 mm) |
|
G1D98/73L20d50 |
98 |
20 |
50 |
Ø73 (10 mm) |
|
G1D98/83L20d46 |
98 |
20 |
46 |
Ø83 (10 mm) |
|
G1D98/83L20d50 |
98 |
20 |
50 |
Ø83 (10 mm) |
|
G1D108/83L20d60 |
108 |
20 |
60 |
Ø83 (10 mm) |
